200 watt dimmable led driver 0-10v Ip20

Product Features:

These drivers are IP20 rated and are suitable for indoor installations. With universal input voltage ranging from 170 to 250VAC, the series of drivers are designed for commercial, industrial and residential applications. Our 0-10V dimming delivers smooth flicker-free linear dimming down to 0% with most LED’s and a wide variety of compatible dimmers. As always, a 3-year warranty is a standard on all Cheng Li xin products.


0-10V dimmable - flicker free down to 0%

IP20 - Indoor Use

Ripple Free

Auto-Reset Protection for Short Circuit and Over-Temperature

Over Load Protection - CC Mode


Product information





DC Voltage


Voltage Accuracy


Rated current


Rated power



 age Range


 Frequency Range


 Power Factor ( Typ.)


 Full Load Efficiency(Typ.)



 Short Circuit

 Hiccup mode, recovers automatically after fault condition is removed.

 Over voltage


 Over temperature

 100°C±10°C shut down o/p voltage, re-power on to recover


 Working TEMP.


 Working Humidity


 Storage TEM.,Humidity





 10~500Hz,5G 12min./1 cycle,period for 72min.each along X,Y,Z axes.


 Safety standards


 Withstand voltage

 I / P- O /P ::3. 75KVAC I/P -FG :1. 88KVAC O/ P -FG :0 . 5KVAC

 Isolation resistance

 I/P-O/P I/P-FG O/P-FG:100MΩ/500VDC/25°C/70%RH


 Compliance to EN61000-4-2,3,4,5,6,8, 11,EN61547,A light industry level


 Compliance toEN55015,EN61000-3-2 (≥50%load)


1. All parameters NOT specially mentioned are measured at 220VAC input , rated load and 25°Cof ambient temperature.

2.Tolerance:includes set us tolerance,line regulation and load regulation .


Product Details

  • Dimension of Product (Unit: mm)

Dimensions: length × width × height = 256(±0.2)×51(±0.2)×29(±0.5)
Location hole size as below:

  • Connecting Drawing

1-10v dimming led driver with dimming 100w 36v
